Specifications
- Made of Stainless Steel AISI 316
- Gasket made in EPDM
- Tempered Glass T = 9 mm
- Reflector: Optical lens, efficiency ≥85%
- Cable gland: IP-68 PG-11 copper with nickel-coated
- Single or RGB (3 in 1) LED
- Mounting sleeve in PVC
- PCB: Excellent heat conductivity aluminium, coefficient of heat, Conductivity ≥ 2.0w /mk. Constant current output.
- Water temperature -20°C to 40°C less than one meter depth
- Power cable: H05RN-F 2 X 0.75 mm2 L = 2 m (12VAC low voltage). H05RN-F 4 x 0.75 mm2 L = 2 m (RGB type)
- DMX / DALI controls compatible Vitrage series upon request
| Concrete Code | Liner Code | Description | Voltage / Power | Beam Angle | Lumen (lm) | Color Temperature |
|---|---|---|---|---|---|---|
| ATZ1201 CW | ATZ1201 CWL | Vitrage 6 LED Cool White | 12V AC/DC / 6×3 W | 30° Symmetrical | 1750 | Cool White 6500K |
| ATZ1201 WW | ATZ1201 WWL | Vitrage 6 LED Warm White | 12V AC/DC / 6×3 W | 30° Symmetrical | 1400 | Warm White 3000K |
| ATZ1201 B | ATZ1201 BL | Vitrage 6 LED Blue | 12V AC/DC / 6×3 W | 30° Symmetrical | 380 | Single Blue |
| ATZ1201 RGB | ATZ1201 RGBL | Vitrage 6 LED Full RGB | 12~24V DC / 6×3 W | 30° Symmetrical | 925 | RGB 14 Modes |
| ATZ1201 RGBW | ATZ1201 RGBWL | Vitrage 6 LED RGBW | 12~24V DC / 6×3 W | 30° Symmetrical | 1400 | RGB 14 Modes / W 3000K |
| Concrete Code | Liner Code | Description | Voltage / Power | Beam Angle | Lumen (lm) | Color Temperature |
|---|---|---|---|---|---|---|
| ATZ1205 CW | ATZ1205 CWL | Vitrage 6 LED Cool White | 12V AC/DC / 6×3 W | 45° Asymmetrical | 1755 | Cool White 6500K |
| ATZ1205 WW | ATZ1205 WWL | Vitrage 6 LED Warm White | 12V AC/DC / 6×3 W | 45° Asymmetrical | 1405 | Warm White 3000K |
| ATZ1205 B | ATZ1205 BL | Vitrage 6 LED Blue | 12V AC/DC / 6×3 W | 45° Asymmetrical | 385 | Single Blue |
| ATZ1205 RGB | ATZ1205 RGBL | Vitrage 6 LED Full RGB | 12~24V DC / 6×3 W | 45° Asymmetrical | 930 | RGB 14 Modes |
| ATZ1205 RGBW | ATZ1205 RGBWL | Vitrage 6 LED RGBW | 12~24V DC / 6×3 W | 45° Asymmetrical | 1405 | RGB 14 Modes / W 3000K |
