Industrial-grade and reliable design | Installation: fresh water and salt water pools
| Specs. | Type |
|---|---|
| Expected Life of UV Lamp | 10,000 hours |
| Technology (Series) | Medium-pressure UV systems (200–600 nm) |
| Max Flow Rate | Up to 616 m³/h at UV dose 60 mJ/cm² |
| Wiper | Manual wiper, Automatic wiper |
| Power Supply | Magnetic power supply |
| Connection | DN125 – DN300 (Flange) |
| Sensor | Temperature sensor, UV sensor, Modbus connection |
| Total Power Input of UV Lamps | 1 – 12 kW |
| Manual Wiper (MW) | Automatic Wiper (AW) | Connection (DN) | Flow Rate – Public Pools & Whirlpools (m³/h) | Total Power Input (kW / Phase) |
|---|---|---|---|---|
| ATECUVM0110-13-MW-DN125 | ATECUVM0110-13-AW-DN125 | 125 | 33 | 1 / I |
| ATECUVM0110-16-MW-DN150 | ATECUVM0110-16-AW-DN150 | 150 | 46 | 1 / I |
| ATECUVM0120-16-MW-DN150 | ATECUVM0120-16-AW-DN150 | 150 | 63 | 2 / III |
| ATECUVM0120-21-MW-DN200 | ATECUVM0120-21-AW-DN200 | 200 | 88 | 2 / III |
| ATECUVM0220-27-MW-DN250 | ATECUVM0220-27-AW-DN250 | 250 | 196 | 4 / III |
| ATECUVM0320-32-MW-DN300 | ATECUVM0320-32-AW-DN300 | 300 | 315 | 6 / III |
| ATECUVM0420-32-MW-DN300 | ATECUVM0420-32-AW-DN300 | 300 | 385 | 8 / III |
| ATECUVM0620-32-MW-DN300 | ATECUVM0620-32-AW-DN300 | 300 | 616 | 12 / III |
