- Pre-filter with a transparent lid in polycarbonate, which allows easy observation of the pre-filter basket.
- Pump body made in polypropylene reinforced with fibreglass, resistant to the chemical products in the swimming pool.
- Noryl impeller with shaft in stainless steel AISI 316
- Mechanical seal in graphite and ceramics.
- Connections of suction and return at: Ø60.3 / 63 mm bush connections.
Save Money
Thanks to the Inverter Technology, the Atecpool InverPro pump consumes less energy than other pumps.
Atecpool InverPro Specifications
| Model | Advised Pool Volume
(m³) |
Noise Level | Input Power
(kW) |
Voltage
(V/Ph/Hz) |
Backwash | Flow (m³/h) | Connections
(mm) |
||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 10m dB(A) |
1m dB(A) |
Q max. | H max. | 6m | 8m | 10m | |||||
| ATECIP09 | 20–30 | 16.6–29.0 | 36.6–49.0 | 0.04–0.35 | 220–240V
1ph |
18.5 | 13.6 | 4.2–9.0 | – | – | 63 |
| ATECIP11 | 25–40 | 17.7–30.4 | 37.7–50.4 | 0.07–0.50 | 23.5 | 17.5 | 9.6–15.0 | 4.5–11.5 | – | 63 | |
| ATECIP15 | 40–55 | 18.5–31.0 | 38.5–51.0 | 0.10–0.70 | 27.5 | 19.1 | 12.9–18.6 | 8.1–15.3 | 8.7–11.1 | 63 | |
| ATECIP22 | 60–80 | 20.0–33.1 | 40.0–53.1 | 0.14–1.0 | 32 | 21 | 13.5–23.1 | 12.0–20.1 | 10.9–16.5 | 63 | |
